Revoria Press EC1100

Revoria Press EC1100

Overview

Revoria Press EC1100 optimally supports a wide range of application and creative finishing versatility, delivering quality image resolution at faster printing speeds, producing improved picture vibrancy, smooth gradation and sharper text.
In addition to its attractive finishing features, the printer is also able to handle long paper and heavyweight paper.

Revoria Press EC1100

Features

Samples

  1. Envelope
  2. Heavyweight (400 gsm)
  3. Long paper (864 mm) 2 sided
  4. Full Bleed Trim
  5. Ticket
  6. Postcard
  7. Business Card
  8. Long Paper (1,200 mm)
  • Note: Samples in this catalog include those that require separate finishing.

Maximum speed of 100 ppm and high productivity on mixed media jobs

Achieve high utilisation rate with the high-performance print engine producing at 100 ppm*1. Print mixed jobs*2 of coated and uncoated paper with minimum downtime along with image quality adjustment optimised when changing paper. Long paper of 330 x 1,200 mm can also be printed at 16 ppm with the Air Suction Feeder.

  • *1: 52 to 300 gsm, A4.
  • *2: When same paper size and speed priority mode is selected.

"Air suction feeder" with high media handling capabilities

Each sheet is picked up and delivered securely by the shuttle head with air suction, improving paper feeding performance for low quality, textured and coated media.

  • Note: Optional configuration.

Paper transport direction

Supports Long Paper of Maximum 1,200 mm

From 98 x 148 mm to 330 x 488 mm, the printer supports a wide range of paper sizes. Equipped for all configurations, the Multi Sheet Inserter for Banner Print can also print on long paper (330 x 660 mm) with the options of one-sided printing on long paper (330 x 1,200 mm) and duplex automatic printing on long paper (330 x 864 mm) that open up new applications and business opportunities.

Supported sizes

Supported sizes

Handles Various Media Weight from 52 gsm to 400 gsm

Everything from thin folded flyers to thick business cards can be printed. Additionally, not only can it handle heavyweight long papers up to 350 gsm* but the efficiency in media handling and versatile printing are able to meet a wide range of customer requirements.

  • *: For one-sided printing of long paper of up to 330 x 660 mm from the optional Air Suction Feeder C1-DSXL or Chained Air Suction Feeder C1-DSXL-L. The supported paper weight differs depending on the feeder and paper length. For details, please check the Brochure.

Wide Variety of Finishing Options

Easily complete jobs from print to finish with automated features of the Revoria Press EC1100 and its wide variety of finishing options, including A3 Cover Sheet Insertion, Punch, Staple, Saddle Staple, Single Fold, Z Fold Half Sheet/Tri-Fold, Crease, Face Trim, Full Bleed Trim, and Square Back.

Finishing Applications

Cover / Sheet Insertion Cover / Sheet Insertion

Punch Punch

Staple Staple

Saddle Staple Saddle Staple

Single Fold Single Fold

Z Fold Half Sheet Z Fold Half Sheet

Tri-Fold Tri-Fold

Crease Crease*1

Face Trim Face Trim

Two-Sided Trim Two-Sided Trim

Full Bleed Trim Full Bleed Trim*2

Square Back Square Back

  • *1: Up to 5 creases are possible for mountain fold and valley fold.
  • *2: Full Bleed Trim is performed for Two-Sided Trim and Face Trim.
  • Note: Optional configuration.

Maximise productivity with Revoria Flow EC11

Print server maximises the productivity of the printer, rapidly processing high capacity jobs at high resolution of 1,200 x 1,200 dpi, 10 bit while also effortlessly handling variable printing and other high capacity jobs.

"Intermediate Data Format" Suppresses Capacity and Processes Jobs at High Speed

Text and images are automatically determined and managed in object units, with high image quality taking priority and processed at high speed while suppressing the capacity.

High-speed processing is achieved by the "RIP Accelerator Board" hardware.

The printer efficiently performs beyond the server's physical specifications, allowing fast output with high-speed tuning.

  • Note: Standard configuration.
"High-Speed Serial Transfer Technology" from Print Server to Printer

The print server processes and transmits data to the printer at 4.25 Gbps/channel* broadband with automated error detection and correction, assuring high reliability.

  • *: 2 channels used in 1 colour.

Revoria Flow EC11

1,200 x 1,200 dpi x 10-bit RIP rendering

Print server maximises the productivity of the printer, rapidly processing high capacity jobs at high resolution of 1,200 x 1,200 dpi, 10 bit while also effortlessly handling variable printing and other high capacity jobs.

Detailed to pixel

Edge enhancement:

Screen processing on contours reproduces crisp texts and lines by suppressing jaggy, which typically occurs on mid-tone lines and texts.

Adjust Invert Text/Line Weight:

Several levels of toner amount are available for selection to apply to the contour, so a desirable balance can be set for better readability of texts. In these processes, the press mitigates crushing of white texts and fattening of black texts when the texts are small.

Rectify errors with Visual Log Display

Easily check user job logs with a timeline function that displays job, printer status and history in chronological order.

Stable Colour Reproduction with 3D Calibration

Revoria Press EC1100 provides accurate colour calibration with Inline Sensor or the X-Rite i1® Pro 3 spectrophotometer. It also supports stable colour reproduction, has a high-resolution 3D calibration feature, includes feedback to support both single and mixed colours.

Automation with Inline Sensor

Save time and improve efficiency with automated adjustments for colour calibration, image-to-media alignment, image transfer adjustment, density uniformity adjustment and tone reproduction curve adjustment.

Optimize print conditions for each paper type

Minimise adjustments when setting up print job with pre-registered paper type setting in the Media Library such as voltage and curl.
Alternatively, you can customise preloaded recommended paper list and save up to 1,000 paper type setting for faster print setup.

From Monitor, On Print

Disregard the need to check colour with each print. The Colour Profile Maker for Display lets you check* the colour of the printed material on your monitor with precision.

  • *: Some colour gamuts cannot be reproduced.

From Monitor, On Print

Auto Sheet Clearing After Paper Jam

Significantly reduce jam clearance time with automated clearing of remaining paper after a jam.

Easy Rectification During Jams

When a paper jam occurs, offset pages are inserted to identify any missing or repeat pages.

Supported Technologies

Supported Technologies

1. Control Panel

Access settings with ease and view job status and errors with the large 10.1-inch Liquid Crystal Touch Panel.

2. VCSEL-ROS / EA-Eco toner*

The VCSEL-ROS provides 2,400 dpi print resolution while the energy-efficient EA-Eco toner* achieves synergistic effect with toner volume control based on coated/uncoated paper to deliver high-quality images comparable to offset printing.

  • *: Emulsion Aggregation-Eco Toner.
3. Air Suction Mechanism / Multifeed Detection Device

The Air Suction Feeder* is installed with our proprietary air suction mechanism to stabilise various paper for high speed feed. The Multifeed Detection Device detects multiple feeding and ensures documents are printed accurately.

  • *: Optional.
4. Gate-Type Registration Mechanism

This mechanism corrects the tilt of paper moving at high speed and stabilises the paper path.

5. Compact Belt Roll Fuser

The compact belt roll fuser ensures uniformity of heat and pressure required to fuse images onto a wide variety of paper stocks including heavyweight.

A. Heat Rollers
B. Pressure Rollers
C. Fusing Pad

 Compact Belt Roll Fuser

6. Built-in Twin Decurler
This machine corrects paper curl, which can negatively affect stable transfer. The amount of correction can be adjusted to match the size and orientation of any type of paper curl.
7. Compact Paper Cooling Device
Stabilised paper transfer and smooth finishing for high-quality print jobs are achieved by the compact paper cooling device.
8. Inline Sensor
Waste no time with adjustments and machine downtime with automated adjustments for colour calibration, image-to-media alignment, image transfer adjustment, density uniformity adjustment and tonal reproduction curve adjustment.
9. Real Time Curl Correction
Adjust the amount of curl in printouts by installing the optional Interface Decurler Module D1.

Remote Services* - Reliable Support System

FUJIFILM Business Innovation Remote Services increase machine reliability, uptime, and productivity - making it easier for us to help you keep your business running smoothly. With remote services, we connect our support systems and tools with skilled teams all over the world, so we can provide responsive assistance when you need it most. This enables us to offer proactive solutions through robust underlying knowledge and comprehensive product understanding.

Remote Services

  • Reduce downtime by transmitting machine data to detect and prevent problems.
  • Keep your printing supplies stocked and automatically delivered, improving utilisation efficiency.
  • Automatically report billing meters to save time and improve accuracy.
  • *: Availability depends on location.

Feeding Options (Max. 10,300 sheets)*

  • *:Main unit + Chained Air Suction Feeder C1-DS-L + Chained Air Suction Feeder C1-DS-R.
One High Capacity Feeder Configuration

High Capacity Feeder C3-DS + Multi Sheet Inserter for Banner Print

High Capacity Feeder C3-DS + Multi Sheet Inserter for Banner Print

  • Air Assist
  • Multifeed Detection
  • 2,000 sheets x 2 trays + 250 sheets
  • Maximum A3, 330 x 488 mm

Air Suction Feeder C1-DS

Air Suction Feeder C1-DS

  • Air Suction
  • Multifeed Detection
  • 2,100 sheets x 2 trays + 250 sheets
  • Maximum A3, 330 x 488 mm

Air Suction Feeder C1-DSXL + Banner Unit for Air Suction Feeder C1-DSXL

Air Suction Feeder C1-DSXL*1 + Banner Unit for Air Suction Feeder C1-DSXL

  • 1,200 mm Long Paper*2
  • Air Suction
  • Multifeed Detection
  • 800 sheets + 2,100 sheets + 250 sheets
  • Maximum A3, 330 x 1,200 mm (Upper Tray)
Two High Capacity Feeder Configuration

2nd High Capacity Feeder C1-DS + High Capacity Feeder C3-DS + Multi Sheet Inserter for Banner Print

2nd High Capacity Feeder C1-DS + High Capacity Feeder C3-DS + Multi Sheet Inserter for Banner Print

  • Air Assist
  • Multifeed Detection
  • 2,000 sheets x 2 trays x 2 units + 250 sheets
  • Maximum A3, 330 x 488 mm

Chained Air Suction Feeder C1-DS-L + Chained Air Suction Feeder C1-DS-R

Chained Air Suction Feeder C1-DS-L + Chained Air Suction Feeder C1-DS-R

  • Air Suction
  • Multifeed Detection
  • 2,100 sheets x 2 trays x 2 units + 250 sheets
  • Maximum A3, 330 x 488 mm

Chained Air Suction Feeder C1-DSXL-L + Chained Air Suction Feeder C1-DS-R + Banner Unit for Air Suction Feeder C1-DSXL

Chained Air Suction Feeder C1-DSXL-L*1 + Chained Air Suction Feeder C1-DS-R + Banner Unit for Air Suction Feeder C1-DSXL

  • 1,200 mm Long Paper*2
  • Air Suction
  • Multifeed Detection
  • 800 sheets + 2,100 sheets + 2,100 sheets x 2 trays + 250 sheets
  • Maximum A3, 330 x 1,200 mm (Upper Tray)
  • Note: The High Capacity Feeder is a required option. Be sure to select a configuration.
  • *1: Only the upper tray allows long paper feeding.
  • *2: During 1 Sided Printing. Up to 330 x 864 mm during Duplex Automatic Print.

Output Options (Max. 14,500 sheets)*

  • *:High Capacity Stacker A1 x 2 + Finisher D6.

Offset Catch Tray

Offset Catch Tray

  • Offset Stack

Long Catch Tray

Long Catch Tray

  • Long paper Stacking

Interface Decurler Module D1

Interface Decurler Module D1

  • Real Time Curl Correction

Inserter D1

Inserter D1

  • Cover / Sheet Insertion

High Capacity Stacker A1

High Capacity Stacker A1

  • 5,000 sheet of Offset Stacking
  • Available in single and dual combinations
  • Stacker Cart
  • Long Paper Stacking*1

Crease / Two-sided Trimmer D2

Crease / Two-sided Trimmer D2

  • Two-sided Trim
  • Crease

Folder Unit CD2

Folder Unit CD2

  • Z Fold Half Sheet
  • Tri-Fold

Square Back Fold Trimmer D1

Square Back Fold Trimmer D1

  • Face Trim
  • Square Back

Finisher D6 / Finisher D6 with Booklet Maker

Finisher D6 / Finisher D6 with Booklet Maker

  • Sort / Stack
  • Punch*1
  • Staple
  • Saddle Staple / Single Fold*2
  • Long Paper Stacking*1
  • Note: For options and trays that can hold long paper output, please check the Brochure.
  • *1: Optional.
  • *2: For Finisher D6 with Booklet Maker.
