[photo] Endoscopic Ultrasonography System workstation

Endoscopic Ultrasonography System

NEW

Next-generation system with high resolution image and endoscopic performance.

The content on this page is intended to healthcare professionals and equivalents.

EG-580UT

Endoscopic functions

Viewing direction

40° (Forward Oblique)

Field of view

140°

Observation range

3-100 mm

Distal end diameter

13.9 mm

Insertion tube diameter

12.4 mm

Minimum diameter of instrument channel

3.8 mm

Bending capability

UP 150° / DOWN 150°
RIGHT 120° / LEFT 120°

Working length

1,250 mm

Total length

1,550 mm

Ultrasonic functions

Scanning mode

Color Doppler, Power Doppler, Pulse Doppler, B-mode, M-mode

Scanning method

Electronic convex scanning method

Scanning angle

150° (Combination with SU-1)

Frequency

5 MHz / 7.5 MHz / 10 MHz / 12 MHz

  • Product : Ultrasonic Endoscope
  • GMDN: 36951
  • Generic Name: Flexible ultrasound gastroduodenoscope

EG-580UR

Endoscopic functions

Viewing direction

Field of view

140°

Observation range

3-100 mm

Distal end diameter

11.4 mm

Insertion tube diameter

11.5 mm

Minimum diameter of instrument channel

2.8 mm

Bending capability

UP 190° / DOWN 90°
RIGHT 100° / LEFT 100°

Working length

1,250 mm

Total length

1,550 mm

Ultrasonic functions

Scanning mode

Color Doppler, Power Doppler, Pulse Doppler, B-mode, M-mode

Scanning method

Electronic radial scanning method

Scanning angle

360° (Combination with SU-1)

Frequency

5 MHz / 7.5 MHz / 10 MHz / 12 MHz

  • Product : Ultrasonic Endoscope
  • GMDN: 36951
  • Generic Name: Flexible ultrasound gastroduodenoscope

EB-530US

Endoscopic functions

Viewing direction

10° (Forward Oblique)

Field of view

120°

Observation range

3-100 mm

Distal end diameter

6.7 mm

Insertion tube diameter

6.3 mm

Minimum diameter of instrument channel

2.0 mm

Bending capability

UP 130° / DOWN 90°

Working length

610 mm

Total length

880 mm

Ultrasonic functions

Scanning mode

Color Doppler, Power Doppler, Pulse Wave, B-mode, M-mode

Scanning method

Electronic convex scanning method

Scanning angle

65° (Combination with SU-1)

Frequency

5 MHz / 7.5 MHz / 10 MHz / 12 MHz

  • Product : Ultrasonic Endoscope
  • GMDN: 44921
  • Generic Name: Flexible ultrasound bronchoscope
