TOKYO, October 15, 2025 – FUJIFILM Corporation announces the launch of “Prescale for High Temperature 100/200”, a pressure measurement film designed for heat pressing processes*1 in semiconductor and automotive manufacturing, available from October 15, 2025.
“Prescale”*2 which Fujifilm holds a leading share in the global market, is a film that enables easy measurement of contact pressure, pressure balance, and distribution between contacting surfaces. The film consists of a color-forming layer and a developer layer. When pressure is applied, microcapsules in the color-forming layer breaks according to the pressure, causing the enclosed color-forming materials to transfer to the developer layer. The red color appears as a result of chemical reaction between the two materials. Furthermore, the color density varies depending on the magnitude of the pressure, allowing users to visually confirm both the pressure distribution and pressure values across the entire surface using color charts and calibration curves. This dependable and visually interpretable pressure indication makes “Prescale” a valuable tool across a wide range of industries, including displays, electronic components, automotive, batteries, and packaging. It is widely used in both development and manufacturing processes to enhance inspection efficiency and quality control.
In recent years, the application of “Prescale” has become increasingly diversified, driven by the advancement of manufacturing processes and growing demands for quality assurance and traceability. There is a rising need for high-accuracy pressure measurement under heated conditions in processes such as automotive press molding, heat sealing in pharmaceutical and food packaging, and wafer bonding*3 in semiconductor manufacturing.
Fujifilm has launched “Prescale for High Temperature 100/200”, a new pressure measurement film designed for heat pressing inspections up to 220°C. By leveraging Fujifilm’s unique high-precision coating technology and advanced microcapsule design technology, and incorporating a heat-resistant base material, “Prescale for High Temperature 100/200” enables highly accurate and stable pressure measurement even under high temperature environments.
Unlike conventional methods that require equipment to be cooled before pressure inspection, “Prescale for High Temperature 100/200” enables direct measurement in high temperature environments. This eliminates the need for cooling and reheating steps, minimizing equipment down-time and contributing to improved inspection efficiency and overall productivity.
In addition, “Prescale for High Temperature 100/200” is now supported by the mobile app “Prescale Mobile”*4 which analyzes color-developed “Prescale” images and converts pressure into numerical data. Along with pressure quantification, the app also features an automatic pass/fail judgment function based on user-defined inspection criteria, further enhancing the quality of pressure inspection in heat pressing processes.
Fujifilm contributes to improving and stabilizing customers' manufacturing quality by developing and providing products that enable the digitalization and optimization of inspection operations in development and manufacturing sites.
- *1 Processing method in which heat and pressure are simultaneously applied to materials to perform molding, bonding, or sintering.
- *2 Film that utilizes Fujifilm’s precision coating technology and microcapsule technology to easily visualize the balance and distribution of pressure and surface pressure. Recommended usage temperature: 20°C to 35°C.
- *3 Process in which multiple wafers or chips are bonded together.
- *4 Mobile application that quantifies pressure from the color-developed image of “Prescale” using Fujifilm’s advanced image processing technology. By placing the developed “Prescale” on a dedicated calibration sheet and scanning it with a mobile device installed with the app, users can easily obtain 13 types of pressure data such as maximum/minimum pressure, average pressure, and pressure area. This simple workflow enables anyone to perform high-precision pressure inspection with ease.
| Product Name | Release Date | Price | Recommended Operating Temperature Measurable Pressure Range |
|---|---|---|---|
| “Prescale for High Temperature 100 LLLW” | October 15, 2025 | Open Price | 35°C–150°C (double-sided heating) 0.2 MPa–0.6 MPa |
| “Prescale for High Temperature 100 LLW” | 35°C–150°C (double-sided heating) 0.5 MPa–2.5 MPa |
||
| “Prescale for High Temperature 100 LW” | Sequentially from February 2026 |
35°C–150°C (double-sided heating) 2.5 MPa–10.0 MPa |
|
| “Prescale for High Temperature 200 LLLW” | 150°C–220°C (double-sided heating) 0.2 MPa–0.6 MPa |
||
| “Prescale for High Temperature 200 LW” | 150°C–220°C (double-sided heating) 2.5 MPa–10.0 MPa |
The “Prescale for High Temperature 100/200” significantly reduces unintended coloring and film deformation under high temperatures through a combination of Fujifilm’s proprietary high-precision coating technology, microcapsule design technology, and heat-resistant base materials. It supports high temperature pressure inspection up to 220°C, enabling stable and highly accurate measurement of pressure distribution in equipment used during heat pressing processes.
“Prescale for High Temperature 100/200” is now compatible with the mobile application “Prescale Mobile,” which analyzes color-developed images and quantifies pressure data. With a simple workflow, users can efficiently obtain quantitative pressure measurements, contributing to improved inspection efficiency and strengthened quality control.
“Prescale for High Temperature 100/200” can be used to measure the pressure of equipment utilized in various heat pressing processes, such as wafer bonding machines in semiconductor manufacturing, heat pressing/lamination machines in substrate production, and heat seal bars in packaging equipment.
“Prescale for High Temperature 100/200” is placed between the wafer and the equipment to measure pressure.
“Prescale for High Temperature 100/200” is placed between the substrate and the equipment to measure pressure.
“Prescale for High Temperature 100/200” is inserted in place of packaging material and pressed by the equipment to measure pressure.
The pressure measurement film “Prescale” is a product of the Advanced Functional Materials Division of FUJIFILM Corporation. This division develops and supplies high-performance materials such as display components, data storage media, industrial equipment, and fine chemicals. By leveraging advanced technologies cultivated through photographic film development—such as precision film formation, coating, and functional molecular design—the division contributes to the advancement of cutting-edge fields including 5G communications, autonomous driving, and smart devices.
Amid ongoing technological innovation and diversifying market needs, the division supports the efficiency of manufacturing operations and the enhancement of product value, thereby contributing to the realization of a safe and secure society.
