STABISCOPE Series
NEWThe gyroscopic stabilization of the STABISCOPE series absorbs the greatest vibrations in the harshest conditions.
![[photo] Pilot looking out the window of helicopter cockpit and sun shining bright in distance over horizon](https://asset.fujifilm.com/www/in/files/2019-09/a5c234a00f828d6a48d0ebd1a70e6e9a/pic_Stabiscope_03.jpg)
The gyro effect created by the flywheel absorbs vibration upto ±5° like that of moving vehicles, helicopters and boats and maintains a steady view.
![[photo] Three flat, glass discs fanned out on top of each other in a straight line on a dark, flat surface](https://asset.fujifilm.com/www/in/files/2019-09/9c44774e817f9aac0dbada2f5bf94c95/pic_Stabiscope_04.jpg)
All lenses and the prisms have a high-quality EBC multi-coating, increasing light permeability for bright, natural color reproduction.
![[photo] White helicopter flying in blue sky with sparse clouds](https://asset.fujifilm.com/www/in/files/2019-09/926f95987fd00a75bee7ca2cc440bc47/pic_Stabiscope_05.jpg)
Strong and corrosion resistant for use in harsh conditions from -20℃ to +50℃. Airtight waterproof structure is filled with dry nitrogen gas to prevent fogging inside. Can be used upside down, allowing the binoculars to be held in either hand.
Lineups
STABISCOPE S1240
- The gyro effect created by the flywheel absorbs the vibration up to ±5° like that of moving vehicles, helicopters and boats and maintains a steady view.
- All lenses and the prisms have a high-quality EBC multi-coating, increasing light permeability for bright, natural color reproduction.
- Strong and corrosion resistant for use in harsh conditions from -20℃ to +50℃.
- Airtight waterproof structure is filled with dry nitrogen gas to prevent fogging inside.
- Can be used upside down, allowing the binoculars to be held in either hand.
![[photo] STABISCOPE S1240 binoculars](https://asset.fujifilm.com/www/in/files/2019-09/a4fe2e6ef44f22887e2d80365294e1c4/pic_Stabiscope_01.png)
Specifications
-
Magnification
-
12
-
Objective diameter (mm)
-
40
-
Field of view (°)
-
4.7
-
Apparent field of view (°) *1
-
52.4
-
Field of view at 1000m (m)
-
82
-
Exit pupil
-
3.3
-
Relative Brightness
-
11.1
-
Eye relief
(mm) -
17
-
Minimum Focus Distance (m) *2
-
28.8
-
Height (mm)
-
210
-
Width (mm)
-
200
-
Depth (mm)
-
90
-
Weight (g)
(w/o Battery) -
1,800
-
Adustment range for interpupillary distance (mm)
-
59-71
-
Dioptric adjustment range (±mm)
-
±5
-
Focus type
-
IF
-
Water resistant*3
-
2m-5min
-
Battery
-
AA×4 or 2CR5×1
-
Operationg temperature
-
−20℃ - +50℃
STABISCOPE S1640
- The gyro effect created by the flywheel absorbs the vibration up to ±5° like that of moving vehicles, helicopters and boats and maintains a steady view.
- All lenses and the prisms have a high-quality EBC multi-coating, increasing light permeability for bright, natural color reproduction.
- Strong and corrosion resistant for use in harsh conditions from -20℃ to +50℃.
- Airtight waterproof structure is filled with dry nitrogen gas to prevent fogging inside.
- Can be used upside down, allowing the binoculars to be held in either hand.
![[photo] STABISCOPE S1640 binoculars](https://asset.fujifilm.com/www/in/files/2019-09/aa7bdeeedfa369bc63467f9b21026382/pic_Stabiscope_02.png)
Specifications
-
Magnification
-
16
-
Objective diameter (mm)
-
40
-
Field of view (°)
-
3.4
-
Apparent field of view (°) *1
-
50.8
-
Field of view at 1000m (m)
-
59
-
Exit pupil
-
2.5
-
Relative Brightness
-
6.3
-
Eye relief (mm)
-
12
-
Minimum Focus Distance (m) *2
-
51.2
-
Height (mm)
-
200
-
Width (mm)
-
200
-
Depth (mm)
-
90
-
Weight (g)
(w/o Battery) -
1,800
-
Adustment range for interpupillary distance (mm)
-
59-71
-
Dioptric adjustment range (±mm)
-
±5
-
Focus type
-
IF
-
Water resistant*3
-
2m-5min
-
Battery
-
CR123A×2
-
Operationg temperature
-
−20℃ - +50℃
- *1 Apparent field of view based on ISO14132-1:2002
- *2 MOD may differ depends on the viewer's sight in case of Indivisual focus.
- *3 Do not mean it can be used in water.
Bundled items: Neck strap, Wristband, DC regulator, input and output cords (for DC regulator), and 4 AA batteries.
