- Field of view
140°
- Viewing direction
0° (Forward)
- Observation range
2〜100 mm
- Bending capability
UP: 210° / DOWN: 90° / RIGHT: 100° / LEFT: 100°
- Working length
1,100 mm
- Total length
1,400 mm
- Distal end diameter
9.2 mm
- Insertion tube diameter
9.3 mm
- Minimum instrument channel diameter
2.8 mm
- Image size
Super image
Product name: Video Endoscope GMDN: 38805
Generic name: Flexible video gastroduodenoscope
- Field of view
170°
- Viewing direction
0° (Forward)
- Observation range
2〜100 mm
- Bending capability
UP: 180° / DOWN: 180° / RIGHT: 160° / LEFT: 160°
- Working length
1,330 mm(M) / 1,520 mm(I) / 1,690 mm(L)
- Total length
1,630 mm(M) / 1,820 mm(I) / 1,990 mm(L)
- Distal end diameter
12.8 mm
- Insertion tube diameter
12.8 mm
- Minimum instrument channel diameter
3.8 mm
- Image size
Super image
Product name: Video Endoscope GMDN: 36117
Generic name: Flexible video colonoscope , reusable
Compatible Endoscopes
Conventional 500 *1 / 600 system scopes can also be used.
700 system scopes | |
600 system scopes | |
500 system scopes *1 | 580 series scopes |
530 series scope *2 |
Available observation mode
White light | BLI | BLI-bright | LCI | FICE | |
---|---|---|---|---|---|
700 system scopes | ○ | ○ | ○ | ○ | ○ |
500/600 system scopes | ○ | - | - | - | ○ |
Accessories (Valve, Tank)
For routine examination
Air/Water Valve
NEWAW-603
Suction Valve
NEWSB-605
Water Tank
NEWWT-603
Used with CO2 Regulator “GW-100”
Gas/Water Valve
NEWAW-604G
Water Tank
NEWWT-604G
