LTO Ultrium Data Cartridge

NEW

FUJIFILM LTO tape is here to help you effectively manage your exponential data growth and preserve digital content sustainably for future generations.

LTO Generation LTO G4 / G4 WORM LTO G5 / G5 WORM LTO G6 / G6 WORM LTO G7 / G7 WORM LTO G8 / G8 WORM Universal Cleaning Cartridge

Basic Specifications

Native Capacity (Compressed)

800 GB (1.6 TB)

1.5 TB (3.0 TB)

2.5 TB (6.25 TB)

6.0TB (15.0TB)

12TB (30TB)

-

Max.Transfer Rate (Compressed)

120 MB/sec. (Up to 240 MB/sec.)

140 MB/sec. (Up to 280 MB/sec.)

160 MB/sec. (Up to 400 MB/sec.)

300 MB/sec. (Up to 750 MB/sec.)

360 MB/sec. (Up to 750 MB/sec.)

-

Number of Tracks

896

1,280

2,176

3,584

6,656

-

Servo Band

Timing-based servo

-

Cartridge Memory

65,280bits (8,160bytes); Internal EEPROM

130,816 bits (16,352 bytes); Internal EEPROM

130,816 bits (16,352 bytes); Internal EEPROM

32,768 bits (4,096 bytes); Internal EEPROM

Estimated Archival life

30years

-

Physical Characteristics

Cartridge Dimensions
(L x W x H)

102 x 105.4 x 21.5 mm

Tape Width

12.65 mm

Tape Thickness

6.6 µm

6.4 µm

6.1 µm

5.6um

8.9 µm

Tape Length

820 m

846 m

960m

319 m

Operating Environmental Conditions

Temperature

10 to 45 °C

Humidity

10 to 80 % (No dew condensation)

Max. Wet Bulb Temperature

26 °C

Storage Environmental Conditions

Temperature
(Short term / Archival)

16 to 35 °C / 16 to 25 °C

Humidity
(Short term / Archival)

20 to 80 % / 20 to 50 % (No dew condensation)

Max. Wet Bulb Temperature

26 °C

Transportation Environmental Conditions

Temperature

-23 to 49°C

Humidity

5% to 80% (No dew condensation)

Max. Wet Bulb Temperature

26 °C
  • * The Universal Cleaning Cartridges are designed for use in all LTO Ultrium 1 through 8 drives.
    Specific revisions of firmware may be required for proper operation.
  • * WORM:WORM(Write Once Read Many)is data cartridge in which information, once written, cannot be modified.
    It is a cost-effective storage capability which ensures data is not overwritten, and to help address compliance regulations.

〇:Read/write △:Read only(no writing) ×:No read/write

Media/Drive G8 Drive G7 Drive G6 Drive G5 Drive G4 Drive
LTO G8 × × × ×
LTO G7 × × ×
LTO G6 × × ×
LTO G5 × ×
LTO G4 × ×

Sustainable packing makes handling and managing LTO tapes significantly easier.

  • Eliminate individual small carton box and hard case, shrink wrapping.
  • Increase productivity (Takes 85% less time to open*1)
  • Reduce waste (waste reduced by 2/3 compared to regular products)
  • Reduce CO2 emissions (85% reduction in production process CO2 emissions)
  • Space saving (Uses approximately 30% less space*2)
  • Cartridges per Pack is 20.
  • *1 Figures obtained by comparing packaging material opening times.
  • *2 Compared to our standard products.

The library pack protects the cartridges against impact if dropped and provides also added protection against dust and humidity.
 It's a good and safe storage and archival solution offering easy and quick unpacking, carrying and piling.

The DATA TAPE COURIER PROFESSIONAL CASE, a new media container made of industrial-strength, lightweight, high-density polyethylene. The case features heavy-duty lockable compression clasps and soft interior contact points that create a durable seal. It can be used to transport data cartridges from one location to another or to off-site storage, in fulfillment of your company's commercial, proprietary and regulatory requirements. The DATA TAPE COURIER PROFESSIONAL CASE is certified and approved by FUJIFILM to protect LTO cartridges and enterprise cartridges.

Product Lineup

PRO CASE WITH LTO TRAY

Holds 18 LTO cartridges in their plastic cases

PRO CASE WITH SOFT LTO TRAY

Holds 14 LTO cartridges without their plastic cases

PRO CASE WITH ENTERPRISE TRAY

Holds 20 Enterprise cartridges
