[photo] Fujifilm 14x40 TECHNO-STABI Series Binocular with a white background

TECHNO-STABI Series - Specifications

Support
OverviewExample usage
Specifications
AccessoriesCatalog

TS-X1440

Binoculars Anatomy

[photo] Fujifilm TECHNO-STABI Series TS-X 1440 Binocular

1．Twist-up eyecups

Eye relief adjustment is easy even for people wearing glasses and for multiple users to share the same eye relief

[photo] Twist-up eyecups

2．Dioptric adjustment ring

Positioned in the front for easy focus adjustment

[photo] Dioptric adjustment ring

3．Compatible with nickel-metal hydride rechargeable batteries

Designed to be set in the battery pack to prevent accidental dropping of batteries when changing batteries

[photo] Compatible with nickel-metal hydride rechargeable batteries

4．Objective Lens

Objective lens cap is included to protect the lens from scratches and dirt during storage

[photo] Objective Lens

5．Non-slip rubber coating & Rounded shape for easy holding

[photo] Non-slip rubber coating & Rounded shape for easy holding

6．Image stabilization ON/OFF switch

Image stabilization switch is a one-push type that does not require holding and has a 10-minute auto-off function to prevent battery drain due to forgetting to turn off the switch

[photo] Image stabilization ON/OFF switch

TS16×28／TS12×28

Binoculars Anatomy

[photo] Fujifilm TECHNO-STABI Series TS16×28/TS12×28 Binocular
  1. Wide-angle lens with a 58.4°apparent field of view for a wide field of vision
  2. Non-slip genuine leather emboss processing
  3. Center focus ring positioned for easy focusing even for people with small hands
  4. Dial switch for easy switching of image stabilization ON/OFF
  5. Twist-up eyecups for easy adjustment and sharing with multiple people
  6. Long eye relief of 16.0mm
    Easy to see even with glasses and less tiring for long hours of use
  7. Less noticeable from surroundings when the image stabilization ON lamp is turned on, making it safe for use at concert venues
  8. Ergonomic design, easy to hold even with one hand
SpecificationsTS-X 1440
(TS-X 1440 Yellow/Navy)		TS12×28WPTS16×28WP

[photo] Fujifilm TECHNO-STABI Series TS-X 1440 Binocular
[photo] Fujifilm TECHNO-STABI Series TS12×28WP Binocular
[photo] Fujifilm TECHNO-STABI Series TS16×28WP Binocular
Magnification141216
Objective diameter (mm)402828
Field of view (°)44.24
Apparent field of view (°)*152.147.558.4
Field of view at 1000m (m)707370
Exit pupil (mm)2.92.31.8
Relative Brightness8.25.43.1
Eye relief (mm)1316.516
Minimum Focus Distance  (m)*253.53.5
Height (mm)179.5148151
Width (mm)165109120
Depth (mm)817474
Weight (g) (w/o Battery)1,300485550
Adjustment range for interpupillary distance (mm)60-7055-7055-70
Dioptric adjustment range (±mm)±2±2±2
Focus typeCFCFCF
Water resistant*31m-5min1m-30min(IPX7)1m-30min(IPX7)
BatteryAA x4 or Ni-MH x4CR2 x1CR2 x1
Operating temperature-10℃～+50℃-10℃～+50℃-10℃～+50℃
  • *1 Apparent field of view based on ISO14132-1:2002
  • *2 MOD may differ depends on the viewer's sight in case of individual focus
  • *3 Do not mean it can be used in water.

Bundled items

TS-X 1440 : Lens cap, eyepiece caps, case, strap and 4 AA alkaline batteries.

TS12x28WP, TS16x28WP : Eyepiece cap, soft-case, neckstrap and CR2 lithium battery.
