Acuity Ultra Series

Acuity Ultra achieves new levels of quality and speed in superwide roll-to-roll printing. It gives you the power to profit from interior and exterior applications, where high-impact, near-photographic quality is desired.


  • Available in 3.2 meter and 5 meter models
  • High quality roll printing output at speeds up to 2,540 square feet/hour (236 square meters/hour)
  • Available in 6-color (CMYKLcLm), 6-color plus white or double CMYK configurations
  • 3.5 picoliter grayscale printheads for remarkable quality
  • Multi-roll printing capabilities enables maximized throughput
  • Chilled vacuum table for handling heat-sensitive materials
  • Very quick start up and simple operator maintenance


Printing Systems
CMYK x 2
Maximum Print Width
3.2 meter Ultra model: 126” (3.2 m)
5 meter Ultra model: 197” (5.0 m)
Media Thickness
Maximum: 0. 078” (2.0 mm)
Minimum: 0.004” (0.1 mm)
Curing System
UV curing lamps with variable power settings
Operational conditions
Temperature: 64˚F – 82˚F (18˚C – 28˚C)
Humidity: 40% – 80% RH (non-condensing)
Atmospheric dust: ≤0.15 mg/m3
Power Supply
3 phase, 400V AC, 60 Hz, 30A
Power consumption: 15 kW
Factory Air Requirement
Pressure (min.): 8 kg/cm2 (7.85 bar / 114 psi)
Flow rate (min.): 1.2 m3/min (1200 l/min / 42.26 cfm)
1000 Base-T
