FUJINON Long Range Multi-Purpose Camera

NEW

The fusion of our vast lens manufacturing technology and our cutting edge image processing technology cultivated in our digital cameras has resulted in our new SX camera series.

Product Brochure (PDF)

SX series (800 / 801 / 1600)

You can download a brochure that covers the features and specifications of the SX series.

SX series brochure

Technical information

You can download various technical information documents. Please enter required information to request a download.

Manual (PDF) / Firmware / CAD data (DXF/STEP) / Drawing data (PDF) / Boundary-line data (PDF) / Pelco command list (PDF) / SX Series Controller

Manual (PDF)

SX800

SX801

SX1600

IP Mode / Stand-Alone Mode

Firmware

Precaution

  • Do not turn the camera off until the update is complete. For firmware update times, please refer to the Firmware Update Guide.
  • The update procedure differs for each model. Please be sure to check the Firmware Update Guide included in the zip file.
  • Please be careful not to mistake the SX800 firmware and the SX801 camera body firmware, as they have the same file name.

SX800

Version Date Remarks
2.31 18/12/2023 If version 1.20 or earlier firmware is in use, the update procedure is different. Please contact the distributor.
If CGI command control with version 1.40 or earlier is in use, please change the login authentication method. Please refer to the latest CGI command specification for details.

ZIP: 32.9MB

SX801

Version Date Remarks
2.12 01/12/2022 The FW version of each module is as follows.
BODY 2.12
IP 1.2.3.1

ZIP: 24.2MB

SX1600

Version Date Remarks
2.10 5/2/2024 The FW version of each module is as follows.
CAMERA 2.10
SYSTEM 2.10
LENS 2.00

ZIP: 53.2MB

CAD data (2D/3D)

SX800

Download

ZIP: 3.0MB

SX801

Download

ZIP: 8.2MB

SX1600

Download

ZIP: 7.4MB

Drawing data (PDF)

Boundary-line data (PDF)

SX800/SX801

Pelco command list (PDF)

SX800/SX801

SX1600

SX Series Controller

Version Date Remarks
1.2.1.0 23/06/2023 Supports SX800 FW ver.2.0 and above.
Supports SX801 FW ver.2.1 and above.
Supports SX1600 FW ver.1.0 and above.

ZIP: 2.2MB

Development documentation

The following development documents are available. If you need the documents, please contact your local sales representative.

Model Support
SX800 CGI Command
SX801
SX1600

License

SX800

 OSSLicense Name
1LinuxGPLv2
2glibc 2.xLGPLV2.1
3BusyboxGPLv2
4opensslApache2
5LibmicrohttpdLGPLV2.1
6libxml2MIT License
7MediaElementMIT License
8HLS.jsApache2
9LibcurlCURL
10gnutlsLGPLV2.1
11pcreBSD
12opensshBSD
13net-toolsGPLv2
14gmpGPLv2
15dhcpISC Equivalent to 2-clause BSD
16alsa-libLGPLV2.1
17nettleGPLv2
18libunistringGPLv2
19libtasn1LGPLV2.1
20iptablesGPLv2
21rng-toolsGPLv2
22live555LGPLV2.1

SX800 Copyright

Download

ZIP: 128KB

SX800 Source code

Download

ZIP:148MB

SX801

 OSSLicense Name
1glibLGPLv2.1
2log4cppLGPLV2.1
3opensslBSD4Clause
4libeventBSD3Clause
5glibcGPLv2
6busyboxGPLv2
7gmpLGPLv3
8curlLGPLv3
9gnutlsLGPLv2.1
10libtasn1LGPLv3
11libunistringLGPLv3
12linuxGPLv2
13nettleGPLv2

SX801 Copyright

Download

ZIP: 205KB

SX801 Source code

Download

ZIP:178MB

SX1600

 OSSLicense Name
1alsa-libLGPLv2.1
2busyboxGPLv2
3dhcpISC Equivalent to 2-clause BSD
4FatFsFatFs
5glibcGPLv2
6glibc 2.xGPLv2 / LGPLV2.1
7gmpGPLv2
8gnutlsLGPLv2.1
9HLS.jsApache2
10iptablesGPLv2
11libc++BSD-Like & MIT
12libcurlCURL
13libcxxrtBSD
14libgccGPL-3.0-with-GCC-exception
15LibmicrohttpdLGPLv2.1
16libtasn1LGPLv2.1
17libunistringGPLv2
18libxml2MIT
19LinuxGPLv2
20live555GPLv3/LGPLV3.0
21MediaElementMIT
22nettleGPLv2
23net-toolsGPLv2
24newlibReference to license
25opensshBSD3Clause
26opensslOpenSSL & Original SSLeay
27pcreBSD3Clause
28rng-toolsGPLv2
29zlibZLIB
30μT-KernelT-Licensev2

SX1600 Source code

Download

ZIP:143MB
