Toner Digital Press

Revoria Press PC1120


Infinite Color Possibilities

1 pass 6-color print engine

In addition to CMYK toner, the press can load a maximum of two Specialty toner stations. For Specialty toner, choices of Clear*1, Gold, Silver, White*2 and Pink toners are available. By overlaying CMYK on Silver or Gold, you can print various brilliant metallic colors. The rich color expressions created by the 6-color print engine can expand your business.

*1: Clear toner can only be used for Overlay.
*2: White toner is avilable only in selected countries.

High resolution printing of 2400 × 2400 dpi

The heart of the printer, ROS*1, uses VCSEL*2 as a light source. It enables printing at 2400 × 2400 dpi high resolution by drawing images simultaneously with multiple laser beams.

*1: Raster Output Scanner
*2: Vertical Cavity Surface Emitting Laser

Super EA*-Eco toner for high image quality

Super EA-Eco toner with extremely small particle size allows smooth reproduction of gradations in photographs, uniform density and sharper fine lines and text. It also produces easy-to-read printed text with less glare.

*: EA: Emulsion Aggregation

Easy and quick adjustment

The in-line sensor is built into the printer body, allowing easy and quick calibration. It also has an automatic adjustment function that allows you to adjust* multiple settings at once. It minimizes the effort required for maintenance and downtime.

*: Batch adjustment of the following can be performed: Auto Alignment Adjustment, Adjust
Image Transfer, Calibration, Density Uniformity Adjustment

Image data processing maximising print engine performance

High quality image data can be generated with RIP processing of 1200 x 1200 dpi and 10 bit (1024 gradation levels) on the Print Server. In addition, high resolution and smooth screen image of 2400 x 2400 dpi can be generated on the device with our unique HQ digital screen technology (MACS*) employed. These data processing technologies can generate high image quality brought from the maximisation of the print engine performance.

*: Micro Accurate Control Screen.

Professional color management system

Supports various CMYK color standards such as Fogra, SWOP and GRACoL

Image Enhancement in a more beautiful way

Higher image quality has been implemented with "Edge Enhancement" that fixes jaggedness on the edge of thin line and text outline and "Adjust Invert Text/Line Weight" that fixes thickened / blurred text.

Note: Default setting: OFF

Selecting different screens for individual objects for optimum image quality

You can select the suitable screen for each object such as a text and photo. The FM screen is effective for moire. Granular roughness that tends to occur on FM screens is suppressed by the dot arrangement suitable for the electrophotography profile, realising a smooth image quality.

Make skin texture beautiful

Equipped with a function to brighten the image using fluorescent Pink toner. By separating into CMYK + Pink, skin tones can be brighter, and the texture of the skin can be reproduced smoothly and beautifully.

Note: You can choose 3 levels of effect. Since the pink layer is generated from magenta, it affects the images containing magenta.

AI-based photo quality optimisation*

AI (Artificial Intelligence) automatically determines the scene for each photographic image on the page and corrects the image appropriately for each of them. low quality images, such as poor contrast and brightness, can be automatically corrected.

*: Applies to RGB type images.

Supporting a wide range of paper weights from lightweight paper of 52 gsm to heavyweight paper of 400 gsm

Paper sizes ranging from A6 to 330 × 488 mm are available. Fullbleed printing on SRA3 (320 × 450 mm) is also possible and it is useful to create brochures or leaflets that need to have bleed.

Supports banner sheet of Maximum 1200 mm

You can print up to 330 x 1200 mm banner sheets for simplex printing*. Widen the scope of new printing application such as powerful panoramic posters.

Note: Please contact our sales representative for paper feeder or output module that is required
for Banner sheet printing
*: Up to 330 x 729 mm for automatic duplex printing.

Eliminate static electricity on Film and Metallic media

Film and metallic medias are easily charged by static electricity when printing, and the printed medias may stick together. However, the in-line static eliminator module* makes it easy to stack and
align these media.

*: Optional "Static Eliminator D1".

Various in-line finishing*

You can create a variety of finished products with full bleed, trimming, crease and folding options.

*: Optional

“Air Suction Feeder*" with enhanced paper handling capabilities

Shuttle head draws up the paper strongly using air, it delivers each sheet securely. This improves paper feeding performance for low quality, textured and coated
*: Optional
