| DK2620JI | DK2623JI | |||||
|---|---|---|---|---|---|---|
| Identifier | -B15- | -B20- | -B25- | -B30- | -B15- | -B20- |
| Slitter portion length | 1.5mm | 2.0mm | 2.5mm | 3.0mm | 1.5mm | 2.0mm |
| Sheath color | Green | Blue | Yellow | Black | Green | Blue |
| Working length*1 | 2,000mm | 2,300mm | ||||
| Maximum diameter of insertion portion |
2.7mm | 2.7mm | ||||
| Instrument channel diameter of compatible endoscope*1 |
2.8mm or more | 2.8mm or more | ||||
| Packaging unit | 1/pack | 1/pack | ||||
- Product name: Diathermic Slitter
DK2620JI (Identifer: -B15x- / -B20- / -B25- / -B30-)
DK2623JI (Identifer: -B15- / -B20-) - GMDN: 61875
- Generic name: Endoscopic electrosurgical electrode, monopolar, single-use
| DK2620JI | DK2623JI | ||||||
|---|---|---|---|---|---|---|---|
| Identifier | -N10- | -N15- | -N20- | -N25- | -N30- | -N15- | -N20- |
| Slitter portion length | 1.0mm | 1.5mm | 2.0mm | 2.5mm | 3.0mm | 1.5mm | 2.0mm |
| Sheath color | White | Green | Blue | Yellow | Black | Green | Blue |
| Working length*1 | 2,000mm | 2,300mm | |||||
| Maximum diameter of insertion portion |
2.7mm | 2.7mm | |||||
| Instrument channel diameter of compatible endoscope*1 |
2.8mm or more | 2.8mm or more | |||||
| Packaging unit | 1/pack | 1/pack | |||||
- Product name: Diathermic Slitter
DK2620JI (Identifer: -N10- / -N15- / -N20- / -N25- / -N30-)
DK2623JI (Identifer: -N15- / -N20-) - GMDN: 61875
- Generic name: Endoscopic electrosurgical electrode, monopolar, single-use
- *1 It is not guaranteed that the equipment chosen only based on the working length and the instrument channel diameter of the endoscope above is compatible.
Do not re-use / Single patient use only
Submucosal injection agent can be supplied via syringe only during ESD.
