Pressure measurement film

Prescale

NEW

This is the only film in the world that can measure pressure.Pressure and pressure distribution, which could not be visually observed in the past, can now be easily confirmed.

Application examples

Main use cases

1. Nip pressure

There are examples of Calender rolls, Rubber roller mounting, Size press rubber rolls, etc.

2. Lamination pressure

There are examples of Dry film resist (DFR) lamination, Backgrind tape lamination roller, Electrophotographic heat fixing parts, etc.

3. Winding pressure

There is an example of Roll product winding.

4. Contact  pressure

There is an example of Brake pads (disk brakes).

5. Compression pressure

There are examples of Vacuum heat pressure devices, Vacuum laminator, Stacking or laminating machines for multilayer ceramic devices, etc.

6. Contact conditions

There are examples of Heat sealing, CMP polishing head, Suction jig for die bonding, etc.

7. Squeegee pressure

There is an example of Squeegee pressure distribution during cream soler printing.

8. Tightening pressure

There is an example of Cylinder head gaskets.

9. Impact pressure

There is an example of The peak impact pressure and its distribution of a ball of softball

Main industry case studies

1. Automobile

There are examples of Cylinder head gaskets, Brake pads, Injection molding machines or molds, Stacking or laminating machines for multilayer ceramic devices, etc.

2. Semiconductor

There are examples of CMP polishing, Backgrind tape lamination roller, Suction jig for die bonding, etc.

3. Printed circuit boards (PCB)

There are examples of  Rubber roller mounting, Squeegee pressure distribution during cream solder printing, Dry film resist (DFR) lamination, etc.

4. Electronics

There are examples of Rubber roller mounting, Squeegee pressure distribution during cream solder printing, Dry film resist (DFR) lamination, etc.

5. Flat-panel displays

There are examples of Rubber roller mounting, Dry film resist (DFR) lamination, Fuel cell stacks and assembly of mobile phones, etc.

6. Battery (PV/FC/LiB)

There are examples of Vacuum laminaor, Cell lamination, Sealing aluminum, etc.

7. Packaging (food/pharmaceutical)

There are examples of Heat sealing, Rubber roll mounting, Molding, etc.

8. Highly functional films

There are examples of Calender roll, Winding, Molding, etc.

9. Other uses

There are examples of Calender roll, Winding, Rubber roller, etc.

Comprehensive catalog

General brochure

This is a General brochure providing a brief introduction to  Prescale. Information such as usage, types of Prescale, strucre, principle and features are written.

Applications for food and pharmaceutical industries

This is a brochre providing applications in food and pharmaceutical industry.

Applications for Smartphones and tablet computers industries

This is a brochure providing applications for Smartphones and Tablet Computers.

Applications for automobile industries

This is a brochure providing applications for automotive industry.
