Apeos C8180 / C7580 / C6580

New Times, New Apeos

Apeos C8180 / C7580 / C6580


  • Copy / Print: Colour/Monochrome 81 ppm*1
  • Scan: Colour/Monochrome 270 ppm*2
  • Fax*3: Super G3 Fax
  • Printing Resolution: 2400 x 2400 dpi
  • Paper Weight: 52 to 350 gsm*4
  • Paper Size: 100 x 148 mm to 330 x 1300 mm
  • Cloud enabled
  • Mobile enabled
  • Supports Long paper
    *1: For C8180. C7580 is 75 ppm, and C6580 is 65 ppm.
    *2: 1 pass, 2 sided scanning.
    *3: Optional.
    *4: When High Capacity Feeder C3-DS option is installed. Up to 300 gsm in standard configuration.
Customer who requires
  • A high-speed, high-quality, and durable device
  • A device that can print in large quantity at a time, such as for a meeting with large audience or many handouts
  • A reliable, working device with core system output such as forms printing
  • A smooth finishing from output to post-processing, such as Folding and Booklet Creation


High durability and large capacity

Combines high productivity and durability to meet the needs for continuous high-volume printing.

  • Low wear photoconductor drum with long life reduces the frequency of drum replacement
  • High-capacity paper feed up to 7360 sheets*1
  • High-capacity toner cartridge*2 and paper tray reduce replacement frequency
  • Replace toner and add paper without stopping the print jobs in progress
  • Excellent durability and ability to handle core output and high volume printing
    *1: 80 gsm paper. When the optional Multi Sheet Inserter and High Capacity Feeder C3-DS are installed.
    *2: High capacity toner cartridges yield approximately 75200 pages (37600 pages x 2) for K toner, and approximately 39700 pages for each colour of CMY toner. This is a reference value when using an A4 original with a 5 % image density for each colour. The actual number of printable sheets varies depending on the usage, original type, and print density, so these values are only a guide.

Fast and efficient operation

Fast startup and output. Reduces waiting time.

  • Achieves print speed as high as 81 ppm*1
  • Smart WelcomEyes detects approaching user, and automatically recovers from a power-saving state
  • High-end model, yet recovers from sleep mode within 30 seconds
  • First Copy Output Time of 5.4 seconds*2
  • Predicts print completion time to help efficient work plan management
    *1: For C8180. C7580 is 75 ppm, and C6580 is 65 ppm.
    *2: Colour priority mode.

Reliable support system

Easy solutions to resolve problems

From supplies replacement to unexpected device failures, most problems can be resolved without waiting for the service representatives or sales representatives.

  1. Resolve problem using the "Help" function on the device
    • Self Help information is available on the control panel
    • Self Help information can be accessed via the mobile device by scanning the QR code displayed on the control panel
  2. "Remote Assistance" with the help of operators
    • Connects directly to the Support Centre
    • An operator will remotely access the multifunction device to resolve the problem by guiding through the steps on the shared control panel


"World's first" high resolution LED printhead print output

Latest technology to achieve professional quality image and high-definition printing.

  • World's first* LED printhead with 2400 dpi resolution.
  • Vibrant colours with Super EA Eco toner and its smallest toner particles for smooth gradation
  • Clear reproduction of images with fine lines and small text
  • Gloss function brings the beautiful glossy finish to the end product (e.g. photos.)
    * Dry-type electrophotographic method. As of March 2021. According to our research.

Highest productivity level with continuous operations

Excellent durability and ability to handle core output and high volume printing.

  • Achieves print speed as high as 81 ppm*1
  • Low wear photoconductor drum with long life reduces the frequency of drum replacement
  • High capacity paper feed up to 7360 sheets*2
  • Replace toner and add paper without stopping the print jobs in progress, and maximise machine runtime
    *1: For C8180. C7580 is 75 ppm, and C6580 is 65 ppm.
    *2: 80 gsm paper. When High Capacity Feeder C3-DS is installed.

Maintain print quality with easy adjustment

Use inbuilt standard SIQA* to easily & quickly adjust the print quality.

  • Simply scan the dedicated charts to automatically calculate the appropriate adjustment values for both Side 1 & 2 Registration, Density Uniformity Adjustment, and Adjust Image Transfer
  • Quick & simple user operation without need of remembering fine calibration values
  • In addition to print quality, machine utilisation rate is also improved
    * Simple Image Quality Adjustment

Powerful, Quiet, Space Saving

We have also taken into consideration the daily usability and ease of installation.

  • The standard Bypass Tray is neatly housed in the main unit of the multifunction device
  • Built-in fax kit*1 in the multifunction device to save space
  • To improve noise reduction, the paper transport and fan design have been optimised
  • Energy-saving designs have been implemented to achieve excellent power consumption reduction with TEC-value*2 1.33 kWh*3
    *1: Optional.
    *2: Typical weekly power consumption as defined by the International Energy Star Program.
    *3: For C8180. C7580 is 1.25 kWh, C6580 is 1.08 kWh. Based on 230 V.

Supporting Technologies
World's first*, LED printhead to achieve 2400 x 2400 dpi high resolution

LED printheads, which are compact and have high image quality, have evolved to be sharper and higher definition.

  • Thin emitting light to write the image
  • The exposure unit does not vibrate because there is no drive mechanism
  • High resolution of 2400 dpi and digital magnification correction
    * Dry-type electrophotographic method. As of March 2021. According to our research.

Share information anytime, anywhere

With Working Folder* and internet access, documents can be viewed regardless of time and location.

  • Can be linked smoothly with multifunction devices, DocuWorks, and mobile devices
  • Documents in Working Folder can be printed from the control panel
  • Scanned documents will be assigned a file name and stored in Working Folder. An email notification will be sent to relevant users

Working Folder

  • Cloud services provided by FUJIFILM Business Innovation. A separate contract is required.

Print out from any multifunction device within the office

With Server-less On-Demand Print*, you have the flexibility to print outs from any of the connected multifunction devices.

  • Improves productivity by printing from another available multifunction device when the current device is in use
  • Up to 100 units can be linked
  • Specific job settings can be revised at the device level to save time (1 sided to 2 sided, all monochrome)
  • Optional.

Flexibility in office layout

Supports wireless LAN environment*1.

  • Supports free addressing in the office with Wi-Fi support
  • Up to five Wi-Fi Direct multifunction devices can be connected at the same time
  • Supports direct mobile printing*2
  • Print Utility, AirPrint, Mopria® Print Service are supported
  • *1: Optional.
  • *2: When connecting to Wi-Fi Direct.

Easy and secure output even when you are working remotely

With Cloud On-Demand Print*, you can register documents from a PC or mobile device to the cloud server and print them from the designated multifunction device.

  • Can be operated securely using a User ID and password
  • Fear of loss or stolen data is minimised
  • No dedicated driver is required
  • Cloud services provided by FUJIFILM Business Innovation. A separate contract is required.

Centralised cloud integration

Cloud Service Hub* allows single sign-on to multiple cloud storage services.

  • Specific storage location can be assigned for scanned documents directly from the multifunction device
  • Searching documents from multiple cloud services is supported
  • Full-text search on scanned documents can be performed with OCR

Cloud Service Hub

  • Cloud services provided by FUJIFILM Business Innovation. A separate contract is required.

Promote in-house production of eye-catching promotional materials

Supports a wide range of paper sizes and thicknesses, and can create a variety of deliverables. You can easily create flyers, business cards, and posters to expand your business.

  • Supports a wide range of sizes from postcards to long paper (330 x 1300 mm*1)
  • Supports a wide range of thicknesses from 52 gsm lightweight paper to 350 gsm*2 cardstock paper
  • Renewed the core technology for image writing, and prints beautifully even on envelopes and embossed paper with uneven surface
    *1: When feeding paper from Bypass Tray of the printer. When printing on one side. 2 sided printing is up to 330 x 762 mm.
    *2: When High Capacity Feeder C3-DS option is installed. Up to 300 gsm in standard configuration.

Print beautifully on various types of paper

Supports the various characteristics of paper, enabling high-precision output.

  • By adjusting the force applied to the paper according to the paper thickness, stable paper feed is performed even with cardstock paper, and high registration accuracy is achieved
  • Built-in decurler flattens paper curl and stabilises paper feed
  • While viewing the amount of curl on paper, adjustments can be performed in real time*
    * Optional.

Enhanced Finishing options

From printing to post-processing, you can do it all at once.

  • Supports frequently-used office functions such as Punch, Side Stitch, Saddle Staple, and Single Fold
  • Finisher-C4 is easy to place in a space-saving office while improving performance such as minimum paper size and the number of sheets for Saddle Staple
  • Finisher D6 with Booklet Maker can perform post-processing for higher-volume output, and also insert covers and separators
  • Slim type Interface Module D1* is also available as a Finisher D6 with Booklet Maker connection module
    Note: Optional. See "Optional" for details on the output options and post-processing.
    * When this module is used, Inserter D1 cannot be connected.

Information is an important asset which should be protected at all cost

Protect from unauthorised user

Multiple options of setting user authorisation allow administrator to select a right combination as per given environment.

  • Local Authentication
  • Authentication by Remote Server*
  • IC Card Authentication*
  • User-specific feature access
  • Private Charge Print
  • Optional.

Additional layer of unwanted access can be created for specific users. (e.g. guests).

  • Secondary Ethernet Kit*
  • Optional.

Protects Data

Protects against any malicious intent of hacking, tampering with device / system settings.

  • Encryption of stored data
  • Uses TPM* 2.0 chip for encryption key management
  • Deletes settings and document information all at once
  • Trusted Platform Module

Protects the information by means of strong encryption while transferring it between devices, servers etc.

  • Encryption of communication paths by SSL/TLS or IPsec
  • Encryption when transferring via SMBv3 and SFTP
  • Scan file encryption/signature
  • Email encryption and signature by S/MIME
  • TLS version limit
  • Elliptic curve cryptography
  • WPA3

Protect from unauthorised access

Protects device settings at multiple levels by clearly demarking change restrictions for different target audience - End users, IT administrators and Service Engineers.

  • Service representative operation restriction
  • Account lock to prevent unauthorised access
  • Information for changing the default password
  • Warnings displayed when using global IP address

Prevents unauthorised program from installing without notice. Robust IT audits are supported with device data logs for easy tracking.

  • Software signature verification
  • Remote update restrictions
  • IP address filtering
  • Tampering detection at startup and automatic restoration when tampering is detected
  • Prevention of tampering during operation
  • Audit log
  • Audit log system transfer

Prevents operation errors

Prevents information leakage due to inadvertent mistakes by administrators and users.

  • Scan documents to be delivered to fixed destination
  • Re-enter fax recipient
  • Annotations
  • Hidden text printing*
  • Digital code embedding and tracking function*
  • Optional.

Feeding Options


Built-in type Bypass Tray (Standard)*1
- 52 to 300 gsm
- 150 sheets
- 1300 mm Long Paper
1. High Capacity Feeder B1
- 52 to 220 gsm
- 2000 sheets x 1-tray
- A4 Size
2. High Capacity Feeder B1-S
- 52 to 300 gsm
- 2000 sheets x 1-tray
- Cabinet
- Air Assist
- Multi-feed Detection
3. High Capacity Feeder C3-DS
- 52 to 350 gsm
- 2000 sheets x 2-tray
- Air Assist
- Multi-feed Detection
Note: Supported paper weight for long paper is 52 to 220 gsm.
*1: Cannot be used when the High Capacity Feeder B1-S or C3-DS is installed.
Option to be installed with High Capacity Feeder B1-S or C3-DS
Multi Sheet Inserter
- 52 to 300 gsm
- 250 sheets
Multi Sheet Inserter for Banner Print
- 52 to 300 gsm
- 250 sheets
- 660 mm Long Paper
Highly functional and high performance Finisher D6 (maximum configuration)


Finisher D6 with Booklet Maker + Interface Decurler Module D1 + Inserter D1 + Folder Unit CD2
- Sort / Stack
- Staple (100 sheets)
- Punch*1
- Saddle Staple (30 sheets) / Single Fold
- Z Fold Half Sheet / Tri-Fold*5
- Long Paper Stacking
- Real Time Curl Correction*6 (3 Levels Upward / Off / 3 Levels Downward)

Note: Simple Catch Tray / Offset Catch Tray / Long Catch Tray are available if post-processing is not required.
*1: Optional.
*2: Staple-free Stapling is available with Finisher-C5 and Finisher-C5 with Booklet Maker.
*3: Function of Folder Unit CD3.
*4: Function of Interface Module D1. When Interface Module D1 is used, the output options that can be connected are: Finisher D6 / Finisher D6 with Booklet Maker, and Folder Unit CD2 only. Inserter D1 cannot be connected.
*5: Function of Folder Unit CD2.
*6: Function of Interface Decurler Module D1.
Post-processing example


Apeos C8180 C7580 C6580 Brochure

File Size:
1.16 MB
Document Type:
Portable Document Format
Download Resource

How To Buy

Apeos C8180 / C7580 / C6580

Contact our sales team

We make it easy for you to purchase products, supplies and services from us. Our extensive network of representatives can help you choose the right solutions for your business needs.
Apeos C8180 / C7580 / C6580
