EB-580S

[standard type]
High-resolution bronchoscope with improved operability thanks to 210°upward bending capability and 2.2mm diameter instrument channel.
-
Field of view
-
120°
-
Observation range
-
2-100mm
-
Distal end diameter
-
5.3mm
-
Insertion tube diameter
-
5.1mm
-
Minimum diameter of instrument channel
-
2.2mm
-
Bending capability
-
UP 210° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
870mm
- Product : Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable



EB-580T

[treatment type]
High-resolution bronchoscope to support efficient treatment.
-
Field of view
-
120°
-
Observation range
-
2-100mm
-
Distal end diameter
-
5.8mm
-
Insertion tube diameter
-
5.9mm
-
Minimum diameter of instrument channel
-
2.8mm
-
Bending capability
-
UP 180° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
870mm
- Product : Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable



EB-530P

[slim type]
Slim type bronchoscope with a 3.8mm slim distal end diameter, suitable for pediatric bronchoscopy.
-
Field of view
-
120°
-
Observation range
-
3-100mm
-
Distal end diameter
-
3.8mm
-
Insertion tube diameter
-
3.8mm
-
Minimum diameter of instrument channel
-
1.2mm
-
Bending capability
-
UP 180° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
890mm
- Product : Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable



EB-530S

[standard type]
Standard type bronchoscope with a slim distal end diameter suitable for observation, biopsy and treatment.
-
Field of view
-
120°
-
Observation range
-
3-100mm
-
Distal end diameter
-
4.9mm
-
Insertion tube diameter
-
4.9mm
-
Minimum diameter of instrument channel
-
2.0mm
-
Bending capability
-
UP 180° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
870mm
- Product name: Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable



EB-530H

[standard type]
Standard type bronchoscope with a wide angle image of 140° that further enhances observation, biopsy and treatment capabilities.
-
Field of view
-
140°
-
Observation range
-
3-100mm
-
Distal end diameter
-
5.4mm
-
Insertion tube diameter
-
4.9mm
-
Minimum diameter of instrument channel
-
2.0mm
-
Bending capability
-
UP 180° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
870mm
- Product name: Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable



EB-530T

[treatment type]
Treatment type bronchoscope with a 2.8mm diameter instrument channel while maintaining the distal end diameter of 5.8mm.
-
Field of view
-
120°
-
Observation range
-
3-100mm
-
Distal end diameter
-
5.8mm
-
Insertion tube diameter
-
5.9mm
-
Minimum diameter of instrument channel
-
2.8mm
-
Bending capability
-
UP 180° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
870mm
- Product name: Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable



EB-530XT

[treatment type]
Treatment type bronchoscope equipped with a 3.2mm diameter instrument channel providing enhanced suction performance. A wider variety of accessories can be used.
-
Field of view
-
120°
-
Observation range
-
3-100mm
-
Distal end diameter
-
6.2mm
-
Insertion tube diameter
-
6.3mm
-
Minimum diameter of instrument channel
-
3.2mm
-
Bending capability
-
UP 180° / DOWN 130°
-
Working length
-
600mm
-
Total length
-
3.2mm
- Product name: Video Endoscope
- GMDN: 17662
- Generic name: Flexible video bronchoscope, reusable
