The content on this page is intended to healthcare professionals and equivalents.
- Field of view
170°
- Viewing direction
0°
- Observation range
2-100 mm
- Bending capability
UP 180° / Down 180°
Right 160° / Left 160- Working length
1,330 mm（M） / 1,690 mm（L）
- Total length
1,650 mm（M） / 2,010 mm（L）
- Distal end diameter
11.5 mm
- Insertion tube diameter
11.5 mm
- Minimum instrument channel diameter
3.2 mm
- Product name: Video endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
170°
- Viewing direction
0°
- Observation range
2-100 mm
- Bending capability
UP 180° / Down 180°
Right 160° / Left 160°- Working length
1,330 mm（M） / 1,520 mm（I） / 1,690 mm（L）
- Total length
1,650 mm（M） / 1,840 mm（I） / 2,010 mm（L）
- Distal end diameter
12.8 mm
- Insertion tube diameter
12.8 mm
- Minimum instrument channel diameter
3.8 mm
- Product name: Video endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
170°
- Viewing direction
0° (Forward)
- Observation range
2～100 mm
- Bending capability
UP: 180° / DOWN: 180°
RIGHT: 160° / LEFT: 160°- Working length
1,330 mm（M）/1,520 mm（I）/1,690 mm（L）
- Total length
1,650 mm（M）/1,840 mm（I）/2,010 mm（L）
- Distal end diameter
12.0 mm
- Insertion tube diameter
12.0 mm
- Minimum diameter of instrument channel
3.8 mm
- Image size
Super image
- Flexibility adjustment mechanism
Available
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
170°
- Viewing direction
0° (Forward)
- Observation range
2～100 mm
- Bending capability
UP: 180° / DOWN: 180°
RIGHT: 160° / LEFT: 160°- Working length
1,330 mm（M）/1,690 mm（L）
- Total length
1,650 mm（M）/2,010 mm（L）
- Distal end diameter
11.1 mm
- Insertion tube diameter
11.5 mm
- Minimum diameter of instrument channel
3.2 mm
- Image size
Super image
- Flexibility adjustment mechanism
Available
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
170°
- Viewing direction
0° (Forward)
- Observation range
2～100 mm
- Bending capability
UP: 180° / DOWN: 180°
RIGHT: 160° / LEFT: 160°- Working length
1,690 mm
- Total length
2,010 mm
- Distal end diameter
12.8 mm
- Insertion tube diameter
12.8 mm
- Minimum diameter of instrument channel
3.8 mm
- Image size
Super image
- Flexibility adjustment mechanism
Available
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
Normal: 140° Closest: 56°
- Viewing direction
0° (Forward)
- Observation range
1.5～100 mm
Normal: 3～100 mm
Closest: 1.5～2.5 mm- Bending capability
UP: 180° / DOWN: 180°
RIGHT: 160° / LEFT: 160°- Working length
1,330 mm（M）/1,690 mm（L）
- Total length
1,650 mm（M）/2,010 mm（L）
- Distal end diameter
12.8 mm
- Insertion tube diameter
12.8 mm
- Minimum diameter of instrument channel
3.8 mm
- Image size
Super image
- Flexibility adjustment mechanism
Available
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
Normal: 140° Closest: 56°
- Viewing direction
0° (Forward)
- Observation range
1.5～100 mm
Normal: 3～100 mm
Closest: 1.5～2.5 mm- Bending capability
UP: 180° / DOWN: 180°
RIGHT: 160° / LEFT: 160°- Working length
1,330 mm(M) / 1,690 mm(L)
- Total length
1,650 mm(M) / 2,010 mm(L)
- Distal end diameter
11.7 mm
- Insertion tube diameter
11.8 mm
- Minimum diameter of instrument channel
3.2 mm
- Image size
Super image
- Flexibility adjustment mechanism
Available
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
140°
- Viewing direction
0° (Forward)
- Observation range
3～100 mm
- Bending capability
UP: 210° / DOWN: 160°
RIGHT: 160° / LEFT: 160°- Working length
1,330 mm（M）/1,690 mm（L）
- Total length
1,630 mm（M）/1,990 mm（L）
- Distal end diameter
9.8 mm
- Insertion tube diameter
10.7 mm
- Minimum diameter of instrument channel
3.2 mm
- Image size
Super image
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
170°
- Viewing direction
0° (Forward)
- Observation range
2〜100 mm
- Bending capability
UP: 180° / DOWN: 180°
RIGHT: 160° / LEFT: 160°- Working length
1,330 mm(M) / 1,520 mm(I) / 1,690 mm(L)
- Total length
1,630 mm(M) / 1,820 mm(I) / 1,990 mm(L)
- Distal end diameter
12.8 mm
- Insertion tube diameter
12.8 mm
- Minimum instrument channel diameter
3.8 mm
- Image size
Super image
- Product name: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
- Field of view
140°
- Viewing direction
0°(Forward)
- Observation range
3~100 mm
- Bending capability
UP 210° / DOWN 90°
RIGHT 100° / LEFT 100°- Working length
1,030 mm
- Total length
1,330 mm
- Distal end diameter
12.8 m
- Insertion tube diameter
12.8 m
- Minimum instrument channel diameter
3.7/3.2 mm
- Image size
Super image
- Product name: Video Endoscope
- GMDN: 64920
- Generic name: Flexible upper/lower gastrointestinal endoscope
![[photo] Lower G.I. scope](https://asset.fujifilm.com/www/uy/files/2025-07/015a8d761286578896a4075a6985a372/pic_colonoscope_01.jpg)
![[photo] Tip of scope, with functioning parts](https://asset.fujifilm.com/www/uy/files/2025-07/f46c8077685daeb57705e92162f9da33/pic_colonoscope_02.jpg)
![[photo] Flexible tip of scope bent downward with forceps sticking out](https://asset.fujifilm.com/www/uy/files/2025-07/c435f08c634993ddfd0e34d8897f28db/pic_colonoscope_03.jpg)
- Viewing direction
0°(Forward)
- Field of view
140°
- Observation range
2-100 mm
- Distal end diameter
12.0 mm
- Insertion tube diameter
12.0 mm
- Minimum diameter of instrument channel
3.8 mm
- Bending capability
UP 180° / DOWN 180°
RIGHT 160° / LEFT 160°- Working length
1,330 mm（M） / 1,520 mm（I） / 1,690 mm（L）
- Total length
1,630 mm（M） / 1,820 mm（I） / 1,990 mm（L）
- Water Jet
Available
- Product: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
![[image] Tip of endoscope with parts - light guide, forceps channel, objective lens, air/water nozzle, and water jet](https://asset.fujifilm.com/www/uy/files/2025-07/aa381fe395ce629270bf13cc532f5edd/fig_colonoscope_01.jpg)
![[image] Scope moves 180 degrees up/down, 160 degrees left/right flexible angles](https://asset.fujifilm.com/www/uy/files/2025-07/c49788f669dab002eb378647298e66dd/fig_colonoscope_02.jpg)
![[image] Image area & forceps entry position](https://asset.fujifilm.com/www/uy/files/2025-07/aac206758fbf4c36661ad18eb2082653/fig_colonoscope_03.jpg)
![[photo] Lower G.I. scope](https://asset.fujifilm.com/www/uy/files/2025-07/663d1f53d74f2ca3b1132771569dff76/pic_colonoscope_04.jpg)
![[photo] Tip of scope, with functioning parts](https://asset.fujifilm.com/www/uy/files/2025-07/c1b155db393ab7502185625d23a9b2fe/pic_colonoscope_05.jpg)
![[photo] Flexible tip of scope bent downward with forceps sticking out](https://asset.fujifilm.com/www/uy/files/2025-07/e3edf5c7f8f7404c2dfcd2c72ccdd0d2/pic_colonoscope_06.jpg)
- Viewing direction
0°(Forward)
- Field of view
Normal: 140° / Closest: 56°
- Observation range
1.5-100 mm
Normal: 3-100 mm
Closest: 1.5-2.5 mm- Distal end diameter
12.8mm
- Insertion tube diameter
12.8mm
- Minimum diameter of instrument channel
3.8mm
- Bending capability
UP 180° / DOWN 180°
RIGHT 160° / LEFT 160- Working length
1,330 / 1,690 mm
- Total length
1,630 / 1,990 mm
- Product: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
![[image] Tip of endoscope with parts - light guide, forceps channel, objective lens, air/water nozzle, and water jet](https://asset.fujifilm.com/www/uy/files/2025-07/fd2bfb02e79e2ec02b86ebf745654029/fig_colonoscope_04.jpg)
![[image] Scope moves 180 degrees up/down, 160 degrees left/right flexible angles](https://asset.fujifilm.com/www/uy/files/2025-07/eb974eb5a95a6f37af1d31d2d6775e1d/fig_colonoscope_05.jpg)
![[image] Image area & forceps entry position](https://asset.fujifilm.com/www/uy/files/2025-07/caaf694250d26cc5d900145c5c032c46/fig_colonoscope_06.jpg)
![[photo] Tip of scope, with functioning parts](https://asset.fujifilm.com/www/uy/files/2025-07/944cb7e5bb113fff374e2eb609ef668c/pic_colonoscope_08.jpg)
![[photo] Flexible tip of scope bent downward to the side](https://asset.fujifilm.com/www/uy/files/2025-07/71ae610d6fe855e481173f818e613267/pic_colonoscope_09.jpg)
- Viewing direction
0°(Forward)
- Field of view
140°
- Observation range
3-100mm
- Distal end diameter
9.8mm
- Insertion tube diameter
10.5mm
- Minimum diameter of instrument channel
3.2mm
- Bending capability
UP 210° / DOWN 160°
RIGHT 160° / LEFT 160°- Working length
EC-580RD/M
1,330mmEC-580RD/L
1,690mm- Total length
EC-580RD/M
1,630mmEC-580RD/L
1,990mm- Water Jet
Available
- Product: Video Endoscope
- GMDN: 36117
- Generic name: Flexible video colonoscope, reusable
![[image] Tip of endoscope with parts - light guide, forceps channel, objective lens, air/water nozzle, and water jet](https://asset.fujifilm.com/www/uy/files/2025-07/18011f7afb82823b629a68c9a65dae92/fig_colonoscope_07.jpg)
![[image] Scope moves 210 degrees up/ 160 degrees down, 160 degrees left/right flexible angles](https://asset.fujifilm.com/www/uy/files/2025-07/54f39276ae863485340235a994d10e75/fig_colonoscope_08.jpg)
![[image] Image area & forceps entry position](https://asset.fujifilm.com/www/uy/files/2025-07/c89ee1a66de5459bf93250a93a473572/fig_colonoscope_09.jpg)
