1/3″ HD ENG Lenses

Model Name: HTs18x4.2BERM
Focal length: [1x]
4.2-76mm
[2x]
8.4-152mm
Zoom ratio: 18x
Extender: 2x
Maximum relative aperture (F-no.): 1 : 1.4 (4.2-76mm) / 1 : 2.8 (8.4-152mm)
Minimum object distance (M.O.D.) from front lens: 0.6m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
4.2mm 697 x 392mm
76mm 41 x 23mm
[2x]
8.2mm 360 x 202mm
152mm 21 x 12mm
Angular field of view 16 : 9 Aspect ratio: [1x]
4.2mm 63.8° × 38.6°
76mm 3.9° × 2.2°
[2x]
8.4mm 34.6° × 19.9°
152mm 2° × 1.1°
Filter thread: M82 x 0.75
Approx. Size: φ85 x 214.1mm(φ x Length)
Approx. Mass: 1.66kg (without lens hood)

Model Name: XT17sx4.5BRM
Focal length: [1x]
4.5-77mm
[2x]
-
Zoom ratio: 17x
Extender: -
Maximum relative aperture (F-no.): 1 : 1.6 (4.5-77mm)
Minimum object distance (M.O.D.) from front lens: 0.95m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
4.5mm 999 x 562mm
77mm 60 x 34mm
[2x]
-
Angular field of view 16 : 9 Aspect ratio: [1x]
4.5mm 60.3° × 36.2°
77mm 3.9° × 2.2°
[2x]
-
Filter thread: M82 x 0.75
Approx. Size: φ85 x 175.6mm(φ x Length)
Approx. Mass: 1.28kg (without lens hood)

Model Name: XT20sx4.7BRM
Focal length: [1x]
4.7-94mm
[2x]
-
Zoom ratio: 20x
Extender: -
Maximum relative aperture (F-no.): 1 : 1.4 (4.7-88mm) / 1 : 1.5 (94mm)
Minimum object distance (M.O.D.) from front lens: 0.9m
Object dimensions at M.O.D. 16 : 9 Aspect ratio: [1x]
4.7mm 901 x 506mm
94mm 47 x 26mm
[2x]
-
Angular field of view 16 : 9 Aspect ratio: [1x]
4.7mm 58.2° × 34.7°
94mm 3.2° × 1.8°
[2x]
-
Filter thread: M82 x 0.75
Approx. Size: φ85 x 189.8mm (φ x Length)
Approx. Mass: 1.48kg (without lens hood)
