LTO Ultrium Data Cartridge : Specifications

Technical Data & Line up Part Number / JAN Code Media/Drive compatibility Library Pack Warranty/Precautions/Disposal of Tape

Technical Data & Line up

LTO Generation	LTO CL	LTO-5/5 WORM	LTO-6/6 WORM	LTO-7/7 WORM	LTO-8/8 WORM	LTO9/9 WORM	LTO-10 (30TB)／ 10 (30TB) WORM	LTO-10 (40TB)
Basic Specifications
Native Capacity (Compressed)	－	1.5TB (3.0TB)	2.5TB (6.25TB)	6TB (15TB)	12TB (30TB)	18TB (45TB)	30TB (75TB)	40TB（100TB）
Max.Transfer Rate^*1 (Compressed)	－	140MB/sec. (Up to 280MB/sec.)	160MB/sec. (Up to 400MB/sec.)	300MB/sec. (Up to 750MB/sec.)	360MB/sec. (Up to 750MB/sec.)	400MB/sec. (Up to 1,000MB/sec.)
Servo Band	－	Timing-based servo
Cartridge Memory	32,786bits (4,096bytes); Internal EEPROM	65,280bits (8,160bytes); Internal EEPROM	130,816bits(16,352bytes); Internal EEPROM			261,888bits (32,736bytes); Internal EEPROM
Physical Characteristics
Tape Width	－	12.65mm
Tape Thickness	8.9μm	6.4μm	6.1μm	5.6μm		5.2μm		4.0μm
Tape Length	319m	846m		960m		1,035m		1,337m
Cartridge Dimensions (L x W x H)	102 x 105.4 x 21.5 mm
Recommended Operation Environment
Temperature	10～45℃					15～25℃		15～35℃
Humidity	10～80%RH					20～50%RH		20～80％RH
Max Wet Bulb Temperature / Max Dew Point Temperature	26℃ (Max Wet Bulb Temperature)					－		22℃ (Max Dew Point Temperature)
Recommended Storage Environment
Temperature	16～35℃(Short Term)/16～25℃(Long Term)					15～25℃		15～35℃
Humidity	20～80%RH(Short Term)/20～50%RH(Long Term)					20～50%RH		20～80％RH
Max Wet Bulb Temperature / Max Dew Point Temperature	26℃ (Max Wet Bulb Temperature)					－		22℃ (Max Dew Point Temperature)
Allowable Operation Environment
Temperature	10～45℃					15～35℃
Humidity	10～80%RH					20～80%RH		10～80％RH
Max Wet Bulb Temperature / Max Dew Point Temperature	26℃ (Max Wet Bulb Temperature)					22℃ (Max Dew Point Temperature)
Allowable Storage Environment
Temperature	16～35℃(Short Term)/16～25℃(Long Term)					15～35℃
Humidity	20～80%RH(Short Term)/20～50%RH(Long Term)					20～80%RH		10～80％RH
Max Wet Bulb Temperature / Max Dew Point Temperature	26℃ (Max Wet Bulb Temperature)					22℃ (Max Dew Point Temperature)

*1 Depends on the drive interface.
* The Universal Cleaning Cartridges (LTO CL) are designed for use in all LTO Ultrium 1 through 10 drives.
Specific revisions of firmware may be required for proper operation.
* WORM：WORM（Write Once Read Many）is data cartridge in which information, once written, cannot be modified.
It is a cost-effective storage capability which ensures data is not overwritten, and to help address compliance regulations.

Part Number / JAN Code

DATA	LTO-5	LTO-6	LTO-7	LTO-8	LTO-9	LTO-10 (30TB)	LTO-10 (40TB)
Part Number	LTO FB UL-5 1.5T J	LTO FB UL-6 2.5T J	LTO FB UL-7 6.0T J	LTO FB UL-8 12.0T J	LTO FB UL-9 18.0T	LTO FB UL-10 30.0T	LTO FB UL-10 40.0T
JAN Code	4547410 119169	4547410 237061	4547410 316971	4547410 364828	4547410 441239	4547410 556902	4547410 572681

WORM	LTO-5 WORM	LTO-6 WORM	LTO-7 WORM	LTO-8 WORM	LTO-9 WORM	LTO-10 (30TB) WORM
Part Number	LTO FB UL-5WORM 1.5T J	LTO FB UL-6WORM 2.5T J	LTO FB UL-7WORM 6.0T J	LTO FB UL-8WORM 12.0T J	LTO FB UL-9WORM 18.0T	LTO FB UL-10WORM 30.0T
JAN Code	4547410 119183	4547410 237078	4547410 316995	4547410 364835	4547410 441246	4547410 556919

The Cleaning Cartridge is universally usable for all LTO-5/6/7/8/9/10 drives. (Someexceptions may apply.)
The WORM type (Write Once Read Many) is a data cartridge that can be recorded onlyonce. It is ideal for securely storing data, as it prevents alterations or accidental deletion ofrecorded data.

Media / Drive compatibility

〇：Read/write　△：Read only(no writing)　×：No read/write
