[photo] FPD-8010E Installation CD

Pressure Distribution Mapping System

FPD-8010E

NEW

Specifications

Product Name

FUJIFILM PRESSURE DISTRIBUTION MAPPING SYSTEM for PRESCALE

Model

FPD-8010E ver. 2.7.0.1

Main Functions

Prescale image input function
Pressure distribution display function/Pressure data output function
3D display function/polar coordinate display function

Scan Sizes

Single Read: 297mm X 210mm(11.7 in X 41.3 in)
Maximum: 891mm X 1050mm(35.1 in X 41.3 in)

Resolution

0.125(200dpi), 0.25(100dpi), 0.5,1,2mm sq.

Dedicated Cover Weight

570g

Dedicated Cover Dimensions

70(H) X 290(W) X 364(D)mm

Components

Dedicated software, dedicated cover, calibration sheet, installation manual, software license

Applicable Scanner

Epson A4 Scanner. Perfection V37/V370, Perfection V600, Perfection V850

Recommended Software Environment

OS

Windows 8, 8.1, 10 (32/64bit)

CPU

2GHz or Higher

Memory

2GB or more

Display

XGA or better, 65,000 colors or more
