[photo] Eluxeo 7000 endoscope system

7000 System

NEW

Endoscope system with diagnosis and usability contains the light source which features high-intensity 4 LED lights.

The content on this page is intended to healthcare professionals and equivalents.

Field of view

140°

Viewing direction

0° (Forward)

Observation range

2~100 mm

Bending capability

UP: 210° / DOWN: 90° / RIGHT: 100° / LEFT: 100°

Working length

1,100 mm

Total length

1,400 mm

Distal end diameter

10.5 mm

Insertion tube diameter

10.8 mm

Minimum diameter of instrument channel

3.8 mm

Image size

Super image

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 38805
  • Generic name: Flexible video gastroduodenoscope
Field of view

140°

Viewing direction

0° (Forward)

Observation range

3~100 mm

Bending capability

UP: 210° / DOWN: 90° / RIGHT: 100° / LEFT: 100°

Working length

1,100 mm

Total length

1,400 mm

Distal end diameter

5.8 mm

Insertion tube diameter

5.9 mm

Minimum diameter of instrument channel

2.4 mm

Image size

Super image

  • Product name: Video Endoscope
  • GMDN: 38805
  • Generic name: Flexible video gastroduodenoscope
Field of view

140°

Viewing direction

0° (Forward)

Observation range

2-100 mm

Image size

Super image

Distal end diameter

9.2 mm

Insertion tube diameter

9.3 mm

Minimum diameter of instrument channel

2.8 mm

Bending capability

UP 210° / DOWN 90°
RIGHT 100° / LEFT 100°

Working length

1,100 mm

Total length

1,400 mm

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 38805
  • Generic name: Flexible video gastroduodenoscope
Field of view

Normal: 140° Closest: 56°

Viewing direction

0° (Forward)

Observation range

1.5-100 mm
Normal: 3-100 mm
Closest: 1.5-2.5 mm

Image size

Super image

Distal end diameter

9.9 mm

Insertion tube diameter

9.8 mm

Minimum diameter of instrument channel

2.8 mm

Bending capability

UP 210° / DOWN 90°
RIGHT 100° / LEFT 100°

Working length

1,100 mm

Total length

1,400 mm

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 38805
  • Generic name: Flexible video gastroduodenoscope
Field of view

170°

Viewing direction

0° (Forward)

Observation range

2~100 mm

Bending capability

UP: 180° / DOWN: 180° / RIGHT: 160° / LEFT: 160°

Working length

1,330 mm(M)/1,520 mm(I)/1,690 mm(L)

Total length

1,650 mm(M)/1,840 mm(I)/2,010 mm(L)

Distal end diameter

12.0 mm

Insertion tube diameter

12.0 mm

Minimum diameter of instrument channel

3.8 mm

Image size

Super image

Flexibility adjustment mechanism

Available

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 36117
  • Generic name: Flexible video colonoscope, reusable
Field of view

170°

Viewing direction

0° (Forward)

Observation range

2~100 mm

Bending capability

UP: 180° / DOWN: 180° / RIGHT: 160° / LEFT: 160°

Working length

1,330 mm(M)/1,690 mm(L)

Total length

1,650 mm(M)/2,010 mm(L)

Distal end diameter

11.1 mm

Insertion tube diameter

11.5 mm

Minimum diameter of instrument channel

3.2 mm

Image size

Super image

Flexibility adjustment mechanism

Available

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 36117
  • Generic name: Flexible video colonoscope, reusable
Field of view

170°

Viewing direction

0° (Forward)

Observation range

2~100 mm

Bending capability

UP: 180° / DOWN: 180° / RIGHT: 160° / LEFT: 160°

Working length

1,690 mm

Total length

2,010 mm

Distal end diameter

12.8 mm

Insertion tube diameter

12.8 mm

Minimum diameter of instrument channel

3.8 mm

Image size

Super image

Flexibility adjustment mechanism

Available

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 36117
  • Generic name: Flexible video colonoscope, reusable
Field of view

Normal: 140° Closest: 56°

Viewing direction

0° (Forward)

Observation range

1.5~100 mm
Normal: 3~100 mm
Closest: 1.5~2.5 mm

Bending capability

UP: 180° / DOWN: 180° / RIGHT: 160° / LEFT: 160°

Working length

1,330 mm(M)/1,690 mm(L)

Total length

1,650 mm(M)/2,010 mm(L)

Distal end diameter

12.8 mm

Insertion tube diameter

12.8 mm

Minimum diameter of instrument channel

3.8 mm

Image size

Super image

Flexibility adjustment mechanism

Available

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 36117
  • Generic name: Flexible video colonoscope, reusable
Field of view

Normal: 140° Closest: 56°

Viewing direction

0° (Forward)

Observation range

1.5~100 mm
Normal: 3~100 mm
Closest: 1.5~2.5 mm

Bending capability

UP: 180° / DOWN: 180° / RIGHT: 160° / LEFT: 160°

Working length

1,330 mm(M) / 1,690 mm(L)

Total length

1,650 mm(M) / 2,010 mm(L)

Distal end diameter

11.7 mm

Insertion tube diameter

11.8 mm

Minimum diameter of instrument channel

3.2 mm

Image size

Super image

Flexibility adjustment mechanism

Available

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 36117
  • Generic name: Flexible video colonoscope, reusable

Field of view

140°

Viewing direction

0° (Forward)

Observation range

3~100 mm

Bending capability

UP: 210° / DOWN: 160° / RIGHT: 160° / LEFT: 160°

Working length

1,330 mm(M)/1,690 mm(L)

Total length

1,630 mm(M)/1,990 mm(L)

Distal end diameter

9.8 mm

Insertion tube diameter

10.7 mm

Minimum diameter of instrument channel

3.2 mm

Image size

Super image

Water jet

Available

  • Product name: Video Endoscope
  • GMDN: 36117
  • Generic name: Flexible video colonoscope, reusable

Accessories (Valve, Tank)

For routine examination

Air/Water Valve

NEW

AW-603

Suction Valve

NEW

SB-605

Water Tank

NEW

WT-603

Used with CO2 Regulator “GW-100”

Gas/Water Valve

NEW

AW-604G

Water Tank

NEW

WT-604G
